Dimensions
5" x 9" x 9-1/2" wide; 38 cm x 23 cm x 24 cm
Drive Units
6.5" 16.5 cm bextrene mid-range bass unit with domed tweeter
Crossover
Electrical two way at 4kHz
Frequency Range
35 Hz 20 kHz
Frequency- Response & Dîstortion Characteristics
See Graphs
Dispersion
See Polar Diagram
Matching Impedence
4 - 8 ohms (see graph)
Efficiency Measured via Pink Noise at 1 metre on axis for 40 watts
99dB
Driving Power Requirements
15 - 40 watts
Nett Weight (each)
6 kgs
